0.16″| 4mm E500 High Density Eva Foam Hardness 50-55° Shore C | 6 Sheets

0.16″| 4mm E500 High Density Eva Foam Hardness 50-55° Shore C | 6 Sheets

Item #: E1220A5055.4MM

$114.00

1/8″ (4mm) thick closed-cell foam is made of smooth EVA  material and absorbs shock while resisting water and UV radiation. It’s easy to cut and shape with a utility knife or a heat gun, making it highly versatile for use in sports gear, footwear, packaging, flooring, props, cosplay costumes, and art. Sold in pack of 6 Sheets.

SKU: E1220A5055.4MM Categories: , Brand:

Description

Eva Foam Hardness 50-55° Shore C | 6 Sheets

What is EVA Foam? Eva Foam consists of Ethylene Vinyl Acetate and blended copolymers, which give an elastic quality. It is chemically cross-linked, resulting in a uniform cell structure and a semi-rigid product for various applications, and has shock-absorbing and buoyancy properties and is resistant to water, UV radiation, and cracking. Available in various thicknesses and densities with a smooth texture on both sides. It is a versatile material that can be shaped with heat, easily glued to other materials, and painted, making it perfect for creative expression. EVA foam has various uses, including thermo molding, footwear for midsoles, accessories, sports equipment, packaging, flooring, and even cosplay props and costumes.

E500 High Density EVA Foam Sheet Size 39″ W x 51″L, 50-55° density  Shore C. Thickness is 1/8″ (4mm)

E500 High Density EVA Foam is also available in 3 mm through 12 mm — see the full 40-55° Shore C range.

Eva foam for orthotics and orthopedic footwear

At 4mm and 50-55° Shore C this is the middle layer of most builds — enough body to shape and post with, soft enough that it accommodates instead of fighting the foot. The 6-sheet pack suits a lab working through a run of devices. Orthotic labs, pedorthists and shoe repair shops reach for this eva foam sheet for:

  • The intermediate layer in three-density diabetic and accommodative inserts
  • Forgiving posts and wedges for patients who cannot tolerate a hard post
  • Full-length insole blanks in shoes with limited depth
  • Light thermoforming over a positive cast for a semi-flexible device
  • Metatarsal pads, bars and reliefs skived to a feathered edge
  • Cushioned lifts, shims and filler in orthopedic footwear

Like the rest of our eva foam range it is closed-cell, so it does not soak up perspiration or lose thickness to it. It heat-forms readily, skives and bevels to a clean edge, and takes contact cement well. Where the build needs control rather than accommodation, step up to the 60-75° Shore C high density range and keep this sheet as the layer above it.

Suitable For:

  • Thermo Molding
  • Footwear
  • Handbag
  • Accessories
  • Sports
  • Padding
  • Packing
  • Flooring
  • Sports Equipment
  • Cosplay

Material Data for EVA :

  • Material: EVA (Ethylene Vinyl Acetate) Grade A
  • Density:185 kg/m3 (nominal)
  • Hardness: 50-55% Shore C
  • Tensile Strength (KPa) L 1700-2000
  • Elongation (%) L 200-220
  • Peeling Strength (N/M) 2000-3000
  • Rebound (%) 36
  • Compression Set % 31.3
  • Sheet Size:  Length 51″ x Width 39″
  • Thickness: 0.16″ (4 mm)
  • Origin: CN
